The one metal sheet model
TECHNICAL Doors

Specifications:
The frame is a welded structure, a fully curved profile with a quarter, which simultaneously forms a molding (angular); can be finished (without molding);
  • the thickness of the metal sheet is 1.0 mm
  • Installation depth of the frame is 70 mm
  • Powder coating (choice of RAL color)
  • The canvas is made by flattening, a sheet of metal 1.0 mm on the outside, 2 stiffening ribs on the inside
  • The thickness of the canvas is 40 mm
  • Sealing one circuit (canvas)
  • Loops 2 pcs.
  • Lower lock (cylindrical, bolt diameter 12 mm)
  • Core cylinder (key-key) with a set of keys
  • Handle on the bar
Additionally to order:
Upper castle (Suwaldny)
 Puller
Ventilation grille
The cost is calculated individually

Metal/Metal model
TECHNICAL Front Doors

Technical characteristics
The frame is a welded structure, a fully curved profile with a quarter, which simultaneously forms a molding (angular). Can be finished (without molding)The thickness of the metal sheet is 1.5 mm. The depth of the frame is 90 mm. Powder coating (choice of RAL color) Sheet metal sheet 1.0 mm on both sides. The thickness of the canvas is 50 mm. Mineral wool insulation (canvas). Sealing one circuit (canvas) Loops 2/4 pcs. Apecs lower lock (mortise cylinder). Core cylinder (key-key) with a set of keys. Apecs handle (on a bar, pressure action, black color).
 Additionally to available:
  • Non-standard sizes
  • Anti-cuts
  • Upper castle
  • Eye
  • Puller
  • Ventilation grill (iron painted according to RAL or stainless steel) with the function of covering blinds
  • Stainless steel handle
  • Stainless threshold pad with WinLock logo

The cost is calculated individually

Metal/Metal model
TECHNICAL interior Doors

Specifications
  • The frame is a welded structure, a fully curved profile with a quarter, which simultaneously forms a molding (angular); can be finished(without molding); the thickness of the metal sheet is 1.5 mm
  • Installation depth of the frame is 60 mm
  • Powder coating (choice of RAL color)
  • Sheet metal sheet 0.8 mm on both sides
  • The thickness of the canvas is 30 mm
  • Mineral wool insulation (canvas)
  • Sealing one circuit (canvas)
  • Loops 2/4 pcs.
  • Apecs lower lock (mortise cylinder)
  • Core cylinder (key-key) with a set of keys
Apecs handle (on a bar, pressure action, black color)

Additionally to available:
  • Non-standard sizes
  • Upper castle
  • Puller
  • Ventilation grill (iron painted according to RAL or stainless steel) with the function of covering blinds
  • Stainless steel handl
  • Stainless threshold pad with WinLock logo

The cost is calculated individually

Metal/MDF model
TECHNICAL Doors

Specifications
  • The frame is a welded structure, a fully curved profile with a quarter; the thickness of the metal sheet is 1.2 mm
  • Depth of the frame is 90 mm
  • Powder coating (choice of RAL color)
  • Sheet metal sheet 1.0 mm
  • The thickness of the canvas is 60 mm
  • Mineral wool insulation (canvas)
  • Sealing one circuit (canvas)
  • Loops 2 pcs.
  • External or internal overlay MDF 10 mm
  • MDF slats 10 mm (if the overlay is external)
  • Kozak lower lock (cylindrical, bolt diameter 12 mm)
  • Core cylinder (key-key) with a set of keys
  • Handle on the bar
Additionally available:
  • Anti-cuts
  • Upper castle: Kozak (Suwaldny)
  • Eye
  • Puller
  • Ventilation grille
  • External or internal lining: MDF 12 or 16 mm
  • Design and color of PVC film (internal or external use)
The cost is calculated individually

FIRE DOORS

From our partners WinLock Inc.
Reliable protection of industrial and residential buildings from the spread of fire and smoke in the event of a fire.
Certificate of compliance with fire resistance limit EI60, EI90

Additional possible equipment:
- Puller
- Retractable threshold
- Stainless steel handle (fireproof on socket)
- A mortise lock set with the "Anti-panic" function and a bar handle
- Door closing coordinator (double-leaf)
- Fireproof glazing up to 0.25% of the canvas area
- Overlay on the canvas HPL-panel (fireproof, for interior or exterior design)

Features

  • The frameis a welded structure, a fully curved profile with a quarter, which simultaneously forms a molding (angular); can be finished (without molding); the thickness of the metal sheet is 1.5 mm

  • Sealing rubber seal against cold smoke on the frame and heat-expandable fire tape on the canvas, which seals the gaps between the frame and the canvas in case of fire.

  • The depth of the frame is 90 mm

  • Powder coating (choice of RAL color)

    .

  • Sheet metal sheet 1.0 mm on both sides. The thickness of the canvas is 50 mm.

  • The inner filling of the canvas is a heat-insulating, fire-resistant material with sound-insulating properties

  • Loops 4/6 pcs.

  • ISEO handle (fireproof on the bar, pressure action, black color)

  • ISEO lock (fireproof mortise cylinder). Core cylinder (key-key) with a set of keys.
